Grey Flexible Insulated Flat Electrical Cable 450V 750V 4 x 10

Detailed Product Description


Grey Insulated And Sheathed Flat Crane Cable , 450 750V 4 x 10

Conductor: superfine copper strands acc. to VDE 0295,class 5
Colour:black(RAL9005) OR Grey(RAL 7001)
Insulation: mixed pvc, resistant to oil, flame resistance and self-exit inguishing

Flat cable_ Flat traveling cable   crane cable   Flat cable for mechanical equipments   flat power cable   PVC flat cable  flat conductor cable  multi core flexible flat cable  flat electric cable
rubber sheathed flat cable  flat copper braided wire  heavy-duty   flat twin cable   flat rubber cable   copper conductor pvc insulated flat cable  flat rubber cable 450/750V rubber insulated and sheathed flat cable    450/750V Submersible pump rubber flat cable



Applications:

As connecting and control cable for cranes and conveyors,it
is suitable for the places of railway stations, crane and other related situations
It is suitable as a control and connection cable for cranes and conveyors on building sites, container goods railway stations and dockyards where operating conditions are rough.


Properties:

Sheath: special polychloreprene(Butadiene-acrylonitrile rubber)
,it remains fexible at -15℃ flame resistance and self-extinguishing


Structure:

Conductor: superfine copper strands acc. to VDE 0295,class 5
Insulation: mixed pvc, resistant to oil, flame resistance and self-exit
                  inguishing
Colour: acc. to 227IEC (brown, blue, black, green/yellow)
             5 cores or more with black number with white digital coding
Sheath: Butadiene-acrylonitrile rubber; resistant to oil, flame retardant
             and self-exitinguishing;
Colour:black(RAL9005) OR Grey(RAL 7001)
Standard: acc. to VDE 0482, part 265-2-2 resp.EN 50265-2-1 and
                 IEC60332-1


Technical data:

Rated voltage: ≤ 1.5mm: 300/500V  ≥ 1.5mm: 450/750V
Test voltage:  ≤ 1.5mm: 2500V         ≥ 1.5mm: 3000 V
Minimum bending radius: 0.3m≤L≤0.6M
Burning vertically test: GB/T1 8380.1-2001, IEC60332-1:1993 test
Passedstandard: GB5023.6 , IEC60227-6, EN50214.
Temperature range: -15℃  to  +70℃
Cables are recommender for installations where the suspended length
doesnt exceed 80m :and the speed of travel does not exceed 4m/s.
if it more than this,with steel.

specification parameter


Flat Traveling Cable

Flat Crane Cable

Grey Flexible Insulated Flat Electrical Cable 450V 750V 4 x 10 Images
